Application:Mooring,Marine,Ship
Application:Mooring,Marine,Ship
Application: Aquaculture, Fish farm mooring
AC-14 anchor is a stockless HHP anchor with a wide anchor crown, thick and long flukes, and longitudinal ribs.
ADA aqua drag anchor is improved version base on generation of aqua-moor DSA anchor, yet provides better performance.
Application:Lifting accessory commonly used in industrial and construction settings.
Product Features: | |
Application: | Ship Anchorage, Ship Docking. |
Material: | Alloy steel,Casting |
Specification: | 10Kgs to 3000Kgs |
Surface: | Hot Dip Galvanizing |
Standard: | European standard/USA ASTM 80 |
Certificate: | LR, ABS, BV, DNV, CCS, KR, NK, RMRS,etc |
Norminal | SIZE(mm) | |||
Weight(kg) | A | B | C | D |
10 | 650 | 400 | 100 | 150 |
25 | 890 | 550 | 130 | 200 |
50 | 960 | 635 | 185 | 230 |
75 | 1105 | 710 | 210 | 266 |
100 | 1215 | 780 | 230 | 293 |
150 | 1395 | 900 | 265 | 336 |
200 | 1535 | 990 | 290 | 370 |
300 | 1755 | 1105 | 330 | 423 |
500 | 2080 | 1335 | 390 | 502 |
700 | 2330 | 1500 | 440 | 560 |
1000 | 2620 | 1685 | 495 | 633 |
2000 | 3300 | 2140 | 625 | 797 |
3000 | 3780 | 2415 | 715 | 912 |
